产品特点
1.全通径 Full Port
2.150磅法兰连接 ANSI 150LB Flange Connection
3.连接尺寸 Size: 1 /2" to 8" (DN15-200)
4.阀体材质 Valve Body Material:Stainless Steel AISI-316(EN10213 1.4408)(ASTM-A351-CF8M) AISI-304(EN10213 1 .4308)(ASTM-A351-CF8)
5.防火设计 Fire-Safe Design
6.采用ISO5211直接安装执行器平台设计 IS0 5211 Direct Mounting Pad
7.带锁定功能手柄 locking device handle
8.阀杆防静电设计 Anti-Static Devices for ball-stem-body
9.阀杆防脱出设计 Blow-out proof stem
10.球槽上有泄压孔设计 Pressure balance hole in ball slot
技术参数
1.设计生产标准：basic Design And Manufacture According To ANSI B16.34
2.结构长度：face-to Face According To ANSI B16.10
3.法兰连接标准：flange Ends According To ANSI B16.5
4.检测标准：inspection And Tested According To Api598
